LED Pixel Tape

We not only have conventional led strip products we offer,but also have customized FPCB led tapes.

There are single color,RGB,RGBW and RGBWW led tapes which cover PWM,SPI, DMX512 LED strips to choose based on your projects.

Also, you can find the hot-seller addressable White,RGB,RGBW LED tapes from DC5V to DC24V at this page.

If you CAN NOT find the product you are looking for, inquiry us freely.

Led Pixel Tape

Quick find by:

Filters
Color
Single Color
RGB
RGBW
Pixel
Addressable
3 led/pixel
6 led/pixel
Protocol
PWM
SPI
DMX512
Voltage
5V
12V
24V
Rating
12V 60 Leds Digital Side emitting RGB Pixel LED strip

12V 60 Leds Digital Side emitting RGB Pixel LED strip

Leave review
Color
RGB
Pixel
3 led/pixel
Protocol
SPI
Voltage
12V

1. 12V Digital side emitting RGB Pixel led strip

2. DC12V, 14W/M

3. 8mm width White /Black FPCB

4. higher brightness than the SK6812 4020 version

5. 2pin / 3pin JST-SM connector

6. 3M adhesive tape on backside of non-waterproof tape

7. Support K-1000C/ K-8000C/ YM-501 /DMX512 control/MADRIX NEBULA,Artnet

8.Protocol compatiable with ws2811,sk6812 4020 led tape

1. The side emitting LED strips, as we known, there are single color side emitting LED strips like 3014 side view led strips; The RGB side emitting LED strips are 020 or 335 RGB side view led strips. But we never saw the digital RGB side emitting LED strips before SK6812 4020 come out.

But SK6812 4020 LED strip is the IC integrated inside 4020 package LED that determin this LED only 5V application.

2. This 12V digital side emitting RGB led strip we choose the SMD4713 RGB LED to make it. 3 LEDs per group to program via WS2811 IC.

3.This is 12V digital Side view RGB pixel led strip 60leds/m with bare board or clearing case and white / black flex pcb. These LED strips are fun and glowy.

4. The LED is “split”, it is side emitting color with 4.7×1.3mm. Lit up these are insanely bright and can be controlled with 8-bit PWM per channel. Great for adding lots of colorful to your project.

5. 12V ws2811 side emitting RGB pixel led strip USE 800 KHz protocol so specific timing is required.

6. Compared to other sk6812 4020 series LEDs, SK6812 side 4020 LEDs has 4 pin even it’s quite thin size, and the Pins are almost covered by the LED’s body, it’s hard to replace LED if any of broken.

But this SMD4713 RGB LED, it has 6 pins even its shorter than the SK6812 4020 RGB LED, would be much stable.

7. Regarding the brightness, SMD4713 RGB LED brightness is higher than the SK68120 4020 version.

8. Vivid lighting performance operated by Arduino, Raspberry Pi , Madrix software, Artnet / DMX512 /MADRIX NEBULA

Read More
High Brightness 12V Addressable RGB 60Leds Pixel LED tape

High Brightness 12V Addressable RGB 60Leds Pixel LED tape

Leave review
Color
RGB
Pixel
Addressable
Protocol
SPI
Voltage
12V

1. High Brightness 12V addressable RGB 60 Pixel LED Strip

2. DC12V, 14.4W/M

3. 10mm width White /Black FPCB

4. Double signal wire, break-point resume function

5. 3M adhesive tape on backside of non-waterproof tape

6. Support K-1000C/ K-8000C/ YM-501 /DMX512 control/MADRIX NEBULA,Artnet

7.Compatiable with SK6813,WS2815 RGB pixel led strip tape

1. This strip is external GS8208 12V addressable RGB 60 Pixel LED Digital Strip that different with addressable 5V RGB led pixel strips like sk6812/ws2812b or ws2813. Actually the protocol is compatible with WS2811 RGB ones.

2.You can think this 12V individually address GS8208 RGB 60 LED strip is the updated version of sk6812, ws2812b.

3. There are integrated GS8208 version individually addressable 12V 30 - 144 pxiels to choose too.

4. Compared to the brightness, this external 12V addressable RGB led strip have higher brightness than the integrated 12V addressable RGB led strip.

5. Vivid lighting performance operated by Arduino, Raspberry Pi , Madrix software, Artnet / DMX512 /MADRIX NEBULA.

6. Why 2 data signal? it is for led strip one led is broken , another data still can work ,unless 2 next led Two successive LED is broken then the led strip can not working . This GS8208 addressable 12V can make the led strip one is broken will not affect another led working.

7. There are two version for this GS8208 version IC. Normally we choose the GS8208B that without demo inside.

8. Widely used in entertainment, stage, live performance, Disco Club and TV Show, etc

Read More
Addressable 60 LEDs Triple White Pixel LED strip

Addressable 60 LEDs Triple White Pixel LED strip

Leave review
Color
RGB
Pixel
Addressable
Protocol
SPI
Voltage
5V

1. Addressable 60 LEDs Triple White Pixel LED strip ( Warm White - White - Cool White)

2. DC5V, 14W/M

3. 10mm width White /Black FPCB

4. 2pin / 3pin JST-SM connector

5. 3M adhesive tape on backside of non-waterproof tape

6. Support K-1000C/ K-8000C/ YM-501 /DMX512 control/MADRIX NEBULA,Artnet

7. Warm White ( 1800-3000K ) -- Warm White ( 4000 - 4500K ) -- White ( 6000 -7000K )

8. Higher Brightness than the SK6812 WWA LED strip

1. These addressable UCS2909 3-in-1 5050 triple white pixel tape are incredibly cool that each color is powered by a channel of UCS2909 IC that enables them to be individually addressable.

2. What an amazing is there are 3 version white CCT can play in one LED strip, especially they are digital white pixel led strip instead of analog white led strips.

3. The strip is made of flexible PCB material, you can cut this stuff pretty easily with wire cutters, there are cut-lines every LED. Solder to the 0.1" copper pads and you're good to go.

4. There not only have 60 pixels addressable UCS2909 triple white digital led tapes to choose, but also addressable SK6812 WWA series digital white pixel led strips.

5. Compared to the SK6812 WWA White pixel LED strip, SK6812 WWA led strip brightness is a little dimmer than this UCS2909 triple white pixel LED strip

6. Vivid lighting performance operated by Arduino, Raspberry Pi , Madrix software, Artnet / DMX512 /MADRIX NEBULA.

Read More
Mini Skinny Addressable 144Leds RGBW pixel led tape

Mini Skinny Addressable 144Leds RGBW pixel led tape

Leave review
Color
RGBW
Pixel
Addressable
Protocol
SPI
Voltage
5V

1. Mini Skinny Addressable 3535 RGBW 144 Pixel LED Digital Strip

2. DC5V, 30W/M

3. 8mm width White /Black FPCB

4. 2pin / 3pin JST-SM connector

5. 3M adhesive tape on backside of non-waterproof tape

6. Warm white 3000K, Neutral White 4500K, Cold white 6500K to choose

7.Support K-1000C/ K-8000C/ YM-501 /DMX512 control/MADRIX NEBULA,Artnet

1. This is Mini skinny addressable RGBW sk6812 144 leds pixel tape on 8mm width are incredibly cool that each led is powered by a sk6812 led that enables them to be individually addressable.

2. We choose SK6812 RGBW LED which it is an intelligent control LED light source that have 4 LEDs (red, green, blue and white) integrated in a package of 3535 components.

3. There are Warm white 3000K, Neutral White 4500K, Cold white 6500K to choose.

4. The LEDs are controlled by shift-registers that are chained up and down the tape so you can shorten or lengthen the tape.

5. SK6812 RGBW LED is single digital out pin ,the PWM is built into each LED-chip so once you set the color you can stop talking to the strip and it will continue to PWM all the LEDs.

6. The addressable RGBW 144 LED strip is made of flexible PCB material, you can cut this stuff pretty easily with wire cutters, there are cut-lines every LED. Solder to the 0.1" copper pads and you're good to go.

7. If the addressable 3535 RGBW 144 led strip does get damaged, it is often one led copper unit broken, in such case, cutting of this copper unit segment and resoldering the rest copper units together brings the strip back to life.

8. Vivid lighting performance operated by Arduino, Raspberry Pi , Madrix software, Artnet / DMX512 /MADRIX NEBULA.

Read More
5V Addressable 60 LEDs WWA White Pixel Led strip

5V Addressable 60 LEDs WWA White Pixel Led strip

Leave review
Color
RGB
Pixel
Addressable
Protocol
SPI
Voltage
5V

1. Addressable 60 LEDs SK6812 WWA White Pixel Led strip

2. DC5V, 14W/M

3. 10mm width White /Black FPCB

4. 2pin / 3pin JST-SM connector

5. 3M adhesive tape on backside of non-waterproof tape

6. Support K-1000C/ K-8000C/ YM-501 /DMX512 control/MADRIX NEBULA,Artnet

7. Amber ( 1800-2000K ) -- Warm White ( 2700 - 3000K ) -- White ( 6000 -7000K )

1. These addressable SK6812 WWA white pixel tape are incredibly cool that each led is powered by a sk6812 that enables them to be individually addressable.

2. What an amazing is there are 3 version white CCT can play in one LED strip, especially they are digital white pixel led strip instead of analog white led strips.

3. SK6812 WWA LED is single digital out pin ,the PWM is built into each LED-chip so once you set the color you can stop talking to the strip and it will continue to PWM all the LEDs.

4. The strip is made of flexible PCB material, you can cut this stuff pretty easily with wire cutters, there are cut-lines every LED. Solder to the 0.1" copper pads and you're good to go.

5. There not only have 60 pixels SK6812 WWA digital led tapes to choose, but also have 30-144 pixels SK6812 WWA digital white pixel led strips and UCS2909 addressable triple white led tape.

6. Compared to the UCS2909 3-in-1 White pixel LED strip, SK6812 WWA led strip brightness is a little dimmer.

7. Vivid lighting performance operated by Arduino, Raspberry Pi , Madrix software, Artnet / DMX512 /MADRIX NEBULA.

Read More
24V 60 Leds DMX512 5-in-1 RGBWW Pixel LED Digital Tape

24V 60 Leds DMX512 5-in-1 RGBWW Pixel LED Digital Tape

Leave review
Color
RGBW
Pixel
6 led/pixel
Protocol
DMX512
Voltage
24V

1. 24V 60 Leds DMX512 RGBWW Pixel LED Digital Tape

2. DC24V, 24W/M

3. 12mm width White / Black FPCB

4. Amber color, Warm white 2700K,Cool white 6500K to choose

5. 60pcs 5-in-1 RGBWW RGBTW LEDs plus 10 pcs DMX512 IC chip

6. 3M adhensive tape on backside of non-waterproof strip

7. Support K-1000C/ K-8000C/ YM-501 /DMX512,Artnet /MADRIX NEBULA to control

8. Widely used in entertainment, stage, live performance, Disco Club and TV Show, etc

1. This strip is 5 colors DMX 512 RGBWW led digital strips that different with normal SPI RGBTW even RGBW led pixel strips.

DMX512 led strips protocl is DMX512 that signal is parallel not series.

2. Its advantage is parallel DMX512 signal could avoid RGBWW LEDs color influenced by the failure of one light in serial connection.

3. Entire strip has 10 pixels ( 50 channels), 60 pcs RGBTW leds in a meter with 12mm width pcb board.

4. Communication between DMX512 led digital strips are synchronized perfectly under support of Artnet / DMX512 led controllers.

5. DMX512 RGBWW led pixel tape strips DMX address need to be set via DMX address coder / controller.

6. Vivid lighting performance operated by Madrix software, Artnet / DMX512 led controllers.

7. 10 pixels 60 leds DMX512 RGBWW led strip is flexible , bright, durable and easy for installation.

8. 5 colors DMX512 RGBWW LED tape is the evolution product based on our DMX512 RGBW LED pixel tape.

Compared to the digital RGBW LED strips,, this DMX512 5-in-1 RGBWW LED strip has much higher brightness and much colors available which colors range from Amber color to cool white  6500K

9. Widely used in entertainment, stage, live performance, Disco Club and TV Show, etc.

Read More
5mm width Addressable 144 Leds RGB Pixel LED tape RGB

5mm width Addressable 144 Leds RGB Pixel LED tape RGB

Leave review
Color
RGB
Pixel
Addressable
Protocol
SPI
Voltage
5V

1. 5mm width Addressable 144 leds RGB Pixel LED strip

2. DC5V, 14W/M

3. 5mm width White /Black FPCB

4. 2pin / 3pin JST-SM connector

5. 3M adhesive tape on backside of non-waterproof tape

6. Neopixel Nano SK6805 2427 RGB LEDs

7.Support K-1000C/ K-8000C/ YM-501 /DMX512 control/MADRIX NEBULA,Artnet

1. This 5mm width Addressable 144 leds RGB Pixel LED strip are incredibly cool that each led is powered by a sk6805 led that enables them to be individually addressable on only 5mm width FPCB.

2. We choose SK6805 2427 RGB LED which it is an intelligent control LED light source that the control circuit and RGB chip are integrated in a package of 2427 components.

3. The SK6805 2427 LEDs are controlled by shift-registers that are chained up and down the tape so you can shorten or lengthen the tape.

4. SK6805 2427 RGB LED is single digital out pin ,the PWM is built into each LED-chip so once you set the color you can stop talking to the strip and it will continue to PWM all the LEDs.

5. The 5mm width Addressable 144 leds RGB Pixel LED strip is made of flexible PCB material on 5mm width, you can cut this stuff pretty easily with wire cutters, there are cut-lines every LED. Solder to the 0.1" copper pads and you're good to go.

6. If the strip does get damaged, it is often one led copper unit broken, in such case, cutting of this copper unit segment and resoldering the rest copper units together brings the strip back to life.

7. There are 5050 12mm width 144 pixels, 3535 7.2mm wdith 144 pixels digital led tapes to choose.

8. Vivid lighting performance operated by Arduino, Raspberry Pi, Madrix,Artnet/DMX/MADRIX NEBULA.

Read More
Addressable Digital RGB COB LED Pixel Strip

Addressable Digital RGB COB LED Pixel Strip

Leave review
Color
RGB
Pixel
Addressable
Protocol
SPI
Voltage
5V

1. Addressable Digital RGB COB LED Pixel Strip

2. DC5V , 332 LEDs/m

3. 12W/m, CRI>80

4. 10mm width FPCB

5. WS2811/WS2812b/SK6812 RGB protocol compitable

6. 3M adhensive tape on backside of non-waterproof strip

7. Support K-1000C/ K-8000C/ YM-501 /DMX512 control/MADRIX NEBULA,Artnet

1. Amazing, this is Addressable Digital RGB COB LED Pixel Strip. Not the single color COB led strip.

2. The COB led strips biggest advantage is no glare, beautiful appearance,soft luminous surface, without spot that compared to the classical addressable rgb pixel led strips like ws2812b,sk6812 led strips

3. The LEDs are controlled by shift-registers that are chained up and down the tape so you can shorten or lengthen the tape.

4. SK6812 RGB LED chip is soldering on the PCB directly, on the top, glue the silicone.

5. The strip is made of flexible PCB material, you can cut this stuff pretty easily with wire cutters on the back side of PCB, there are cut-lines .Solder to the 0.1" copper pads and you're good to go.

6. If the strip does get damaged, it is often one led copper unit broken, in such case, cutting of this copper unit segment and resoldering the rest copper units together brings the strip back to life.

7. For the addressable digital RGB COB led pixel tape, we only have 332 leds/m currently

8. Vivid lighting performance operated by Arduino, Raspberry Pi, Madrix,Artnet/DMX/MADRIX NEBULA.

9. The COB LED strips, consider the high density leds, we do not recommend to choose the IP67 or IP68.

Read More
COB Single color LED Strip

COB Single color LED Strip

Leave review
Color
Single Color
Pixel
6 led/pixel
Protocol
PWM
Voltage
24V

1. COB Single color LED Strip

2. DC5V / DC12V / DC24V , 528 LEDs/m

3. 11W/m, CRI>80 or CRI>90

4. 8mm width FPCB

5. White/RED/BLUE/GREEN/YELLOW/UV LEDs are available

6. 3M adhensive tape on backside of non-waterproof strip

7. Support PWM LED controller can achieve uniform color temperature and brightness adjustment

1. This is COB Single color LED Strip 528 LEDs tape. Not digital led strip, only analog single color.

2. The matched control system can achieve uniform color temperature and brightness adjustment.

3. The COB led strips biggest advantage is no glare, beautiful appearance,soft luminous surface, without spot that compared to the classical single color led strips like 5050,2835 ,even 2110 led strips

4. For the White LEDs, there are 2200K to 10,000K white CCT to choose.

5. CRI>80,CRI>90 are available to offer.

6. There are 320 leds, 384 leds COB LED strips to choose.

7. Amazing is we also have addressable rgb pixel COB led strip.

8. Integrated package solution for more uniform and consistent light mixing

9. Wide range of illumination for more compact lighting space.

10. For white color, high color consistency, within 5 steps SDCM(3 steps Optional).

11. The COB LED strips, consider the high density leds, we do not recommend to choose the IP67 or IP68.

12. If there was defctive leds, you just cut the segment based on the pads, then solder it.

Read More
