LED Pixel Tape

We not only have conventional led strip products we offer,but also have customized FPCB led tapes.

There are single color,RGB,RGBW and RGBWW led tapes which cover PWM,SPI, DMX512 LED strips to choose based on your projects.

Also, you can find the hot-seller addressable White,RGB,RGBW LED tapes from DC5V to DC24V at this page.

If you CAN NOT find the product you are looking for, inquiry us freely.

Led Pixel Tape

Quick find by:

Filters
Color
Single Color
RGB
RGBW
Pixel
Addressable
3 led/pixel
6 led/pixel
Protocol
PWM
SPI
DMX512
Voltage
5V
12V
24V
Rating
5V Addressable 30Leds RGB pixel led tape

5V Addressable 30Leds RGB pixel led tape

Leave review
Color
RGB
Pixel
Addressable
Protocol
SPI
Voltage
5V

1. Addressable RGB 30 Pixel LED Digital Strip

2. DC5V, 6W/M

3. 10mm width White /Black FPCB

4. 2pin / 3pin JST-SM connector

5. 3M adhesive tape on backside of non-waterproof tape

6. Support K-1000C/ K-8000C/ YM-501 /DMX512 control/MADRIX NEBULA,Artnet

7.Compatiable with ws2811,WS2812b RGB pixel led strip tape

1. These addressable ws2812b sk6812 30 leds RGB pixel tape are incredibly cool that each led is powered by a sk6812/ws2812b led that enables them to be individually addressable.

2. We choose SK6812/WS2812b RGB LED which it is an intelligent control LED light source that the control circuit and RGB chip are integrated in a package of 5050 components.

3. The LEDs are controlled by shift-registers that are chained up and down the tape so you can shorten or lengthen the tape.

4. SK6812 RGB LED is single digital out pin ,the PWM is built into each LED-chip so once you set the color you can stop talking to the strip and it will continue to PWM all the LEDs.

5. The strip is made of flexible PCB material, you can cut this stuff pretty easily with wire cutters, there are cut-lines every LED. Solder to the 0.1" copper pads and you're good to go.

6. If the strip does get damaged, it is often one led copper unit broken, in such case, cutting of this copper unit segment and resoldering the rest copper units together brings the strip back to life.

7. There not only have 60 pixels to 144 pixels digital led tapes to choose, but also have 12V addressable RGB 30 pixels to 144 pixels led tapes.

8. Vivid lighting performance operated by Arduino, Raspberry Pi, Madrix,Artnet/DMX/MADRIX NEBULA.

Read More
5V Addressable 144Leds RGB pixel led tape

5V Addressable 144Leds RGB pixel led tape

Leave review
Color
RGB
Pixel
Addressable
Protocol
SPI
Voltage
5V

1. Addressable RGB 144 Pixel LED Digital Strip

2. DC5V, 30W/M

3. 12mm width White /Black FPCB

4. 2pin / 3pin JST-SM connector

5. 3M adhesive tape on backside of non-waterproof tape

6. Support K-1000C/ K-8000C/ YM-501 /DMX512 control/MADRIX NEBULA,Artnet

7.Compatiable with ws2811,WS2812b RGB pixel led strip tape

1. These addressable ws2812b sk6812 144 leds RGB pixel tape are incredibly cool that each led is powered by a sk6812/ws2812b led that enables them to be individually addressable.

2. We choose SK6812/WS2812b RGB LED which it is an intelligent control LED light source that the control circuit and RGB chip are integrated in a package of 5050 components.

3. This 144 pixel led tapes are ultra-high density which are ready for you to blink.

4. The LEDs are controlled by shift-registers that are chained up and down the tape so you can shorten or lengthen the tape.

5. SK6812 RGB LED is single digital out pin ,the PWM is built into each LED-chip so once you set the color you can stop talking to the strip and it will continue to PWM all the LEDs.

6. The strip is made of flexible PCB material, you can cut this stuff pretty easily with wire cutters, there are cut-lines every LED. Solder to the 0.1" copper pads and you're good to go.

7. If the strip does get damaged, it is often one led copper unit broken, in such case, cutting of this copper unit segment and resoldering the rest copper units together brings the strip back to life.

8. There not only have 30 pixels to 60 pixels digital led tapes to choose, but also have 12V addressable RGB 30 pixels to 144 pixels led tapes.

9. Vivid lighting performance operated by Arduino, Raspberry Pi , Madrix software, Artnet / DMX512 /MADRIX NEBULA.

Read More
5V Addressable 60Leds RGB pixel led tape

5V Addressable 60Leds RGB pixel led tape

Leave review
Color
RGB
Pixel
Addressable
Protocol
SPI
Voltage
5V

1. Addressable RGB 60 Pixel LED Digital Strip

2. DC5V, 12W/M

3. 10mm width White /Black FPCB

4. 2pin / 3pin JST-SM connector

5. 3M adhesive tape on backside of non-waterproof tape

6. Support K-1000C/ K-8000C/ YM-501 /DMX512 control/MADRIX NEBULA,Artnet

7.Compatiable with ws2811,WS2812b RGB pixel led strip tape

1. These addressable ws2812b sk6812 60 leds RGB pixel tape are incredibly cool that each led is powered by a sk6812/ws2812b led that enables them to be individually addressable.

2. We choose SK6812/WS2812b RGB LED which it is an intelligent control LED light source that the control circuit and RGB chip are integrated in a package of 5050 components.

3. The LEDs are controlled by shift-registers that are chained up and down the tape so you can shorten or lengthen the tape.

4. SK6812 RGB LED is single digital out pin ,the PWM is built into each LED-chip so once you set the color you can stop talking to the strip and it will continue to PWM all the LEDs.

5. The strip is made of flexible PCB material, you can cut this stuff pretty easily with wire cutters, there are cut-lines every LED. Solder to the 0.1" copper pads and you're good to go.

6. If the strip does get damaged, it is often one led copper unit broken, in such case, cutting of this copper unit segment and resoldering the rest copper units together brings the strip back to life.

7. There not only have 60 pixels to 144 pixels digital led tapes to choose, but also have 12V addressable RGB 30 pixels to 144 pixels led tapes.

8. Vivid lighting performance operated by Arduino, Raspberry Pi , Madrix software, Artnet / DMX512 /MADRIX NEBULA.

Read More
Addressable 60Leds RGBW pixel led tape

Addressable 60Leds RGBW pixel led tape

Leave review
Color
RGBW
Pixel
Addressable
Protocol
SPI
Voltage
5V

1. Addressable RGBW 60 Pixel LED Digital Strip

2. DC5V, 12W/M

3. 10mm width White /Black FPCB

4. 2pin / 3pin JST-SM connector

5. 3M adhesive tape on backside of non-waterproof tape

6. Warm white 3000K, Neutral White 4500K, Cold white 6500K to choose

7.Support K-1000C/ K-8000C/ YM-501 /DMX512 control/MADRIX NEBULA,Artnet

1. These addressable RGBW ws2812b sk6812 60 leds pixel tape are incredibly cool that each led is powered by a sk6812 led that enables them to be individually addressable.

2. We choose SK6812 RGBW LED which it is an intelligent control LED light source that have 4 LEDs (red, green, blue and white) integrated in a package of 5050 components.

3. There are Warm white 3000K, Neutral White 4500K, Cold white 6500K to choose.

4. The LEDs are controlled by shift-registers that are chained up and down the tape so you can shorten or lengthen the tape.

5. SK6812 RGBW LED is single digital out pin ,the PWM is built into each LED-chip so once you set the color you can stop talking to the strip and it will continue to PWM all the LEDs.

6. The addressable RGBW 60 LED strip is made of flexible PCB material, you can cut this stuff pretty easily with wire cutters, there are cut-lines every LED. Solder to the 0.1" copper pads and you're good to go.

7. If the addressable RGBW 60 led strip does get damaged, it is often one led copper unit broken, in such case, cutting of this copper unit segment and resoldering the rest copper units together brings the strip back to life.

8. There not only have 30 pixels to 144 pixels RGBW digital led tapes to choose, but also have 12V addressable RGBW 30 pixels to 60 pixels led tapes.

9. Vivid lighting performance operated by Arduino, Raspberry Pi , Madrix software, Artnet / DMX512 /MADRIX NEBULA.

Read More
12V 60Leds DMX512 RGB LED Digital Tape

12V 60Leds DMX512 RGB LED Digital Tape

Leave review
Color
RGB
Pixel
3 led/pixel
Protocol
DMX512
Voltage
12V

1. DMX512 RGB 20 Pixels 60 LED Digital Strip

2. DC12V, 14W/M

3. 12mm width White / Black FPCB

4. 3M adhensive tape on backside of non-waterproof strip

5. Support K-1000C/ K-8000C/ YM-501 /DMX512,Artnet to control

6.Standard DMX512 Signal wire digital control interface A,B

7. Widely used in entertainment, stage, live performance, Disco Club and TV Show, etc

1. This strip is 12V DMX 512 RGB 60 led digital strips that different with normal SPI led pixel strips.

DMX512 led strips protocl is DMX512 that signal is parallel not series.

2. Its advantage is parallel DMX512 signal could avoid RGB LEDs color influenced by the failure of one light in serial connection.

3. Entire strip has 20 pixels ( 60 channels), 60 pcs RGB leds in a meter with 12mm width pcb board.

4. Communication between DMX512 led digital strips are synchronized perfectly under support of Artnet / DMX512 led controllers.

5. DMX512 RGB led pixel tape strips DMX address need to be set via DMX address coder / controller.

6. Vivid lighting performance operated by Madrix software, Artnet / DMX512 led controllers.

7. There are single DMX512 Signal wire digital control interface A led strips to choose.

8. 10 pixels 60 leds DMX512 RGB led strip is flexible , bright, durable and easy for installation.

For bare board strip, you can use the 3M adhensive tape on back; For waterproof silicone tube strip, there shipped with flexible silicon brackets and screws, the brackets fit over the waterproof sheath, it would be used to mount the led strips very well.

9. Widely used in entertainment, stage, live performance, Disco Club and TV Show, etc.

Read More
24V 60 Leds DMX512 RGB Pixel LED Digital Tape

24V 60 Leds DMX512 RGB Pixel LED Digital Tape

Leave review
Color
RGB
Pixel
6 led/pixel
Protocol
DMX512
Voltage
24V

1. DMX512 RGB Pixel LED Digital Strip

2. DC24V, 14W/M

3. 12mm width White / Black FPCB

4. 3M adhensive tape on backside of non-waterproof strip

5. Support K-1000C/ K-8000C/ YM-501 /DMX512,Artnet to control

6.Standard DMX512 Signal wire digital control interface A,B

7. Widely used in entertainment, stage, live performance, Disco Club and TV Show, etc

1. This strip is DMX 512 RGB led digital strips that different with normal SPI led pixel strips.

DMX512 led strips protocl is DMX512 that signal is parallel not series.

2. Its advantage is parallel DMX512 signal could avoid RGB LEDs color influenced by the failure of one light in serial connection.

3. Entire strip has 10 pixels ( 30 channels), 60 pcs RGB leds in a meter with 12mm width pcb board.

4. Communication between DMX512 led digital strips are synchronized perfectly under support of Artnet / DMX512 led controllers.

5. DMX512 RGB led pixel tape strips DMX address need to be set via DMX address coder / controller.

6. Vivid lighting performance operated by Madrix software, Artnet / DMX512 led controllers.

7. There are single DMX512 Signal wire digital control interface A led strips to choose.

8. 10 pixels 60 leds DMX512 RGB led strip is flexible , bright, durable and easy for installation.

For bare board strip, you can use the 3M adhensive tape on back; For waterproof silicone tube strip, there shipped with flexible silicon brackets and screws, the brackets fit over the waterproof sheath, it would be used to mount the led strips very well.

9. Widely used in entertainment, stage, live performance, Disco Club and TV Show, etc.

Read More
12V 72 Leds DMX512 RGBW Pixel LED Digital Tape

12V 72 Leds DMX512 RGBW Pixel LED Digital Tape

Leave review
Color
RGBW
Pixel
3 led/pixel
Protocol
DMX512
Voltage
12V

1. DMX512 RGBW RGBWW Pixel LED Digital Strip

2. DC12V, 23W/M

3. 12mm / 15mm width FPCB

4. Warm white 3000K, neutral white 4500K, Cool white 6500K to choose

5. 3M adhensive tape on backside of non-waterproof strip

6. Support K-1000C/ K-8000C/ YM-501 /DMX512 control,Artnet to control

7.Standard DMX512 Signal wire digital control interface A,B

8. Widely used in entertainment, stage, live performance, Disco Club and TV Show, etc

1. This strip is DMX 512 RGBW led digital strips that different with normal SPI led pixel strips. DMX512 led strips protocl is DMX512 that signal is parallel not series.

2. Its advantage is parallel DMX512 signal could avoid RGBW LEDs color influenced by the failure of one light in serial connection.

3. Entire strip has 24 pixels ( 96 channels), 72 pcs RGBW leds in a meter with 12mm /15mm width pcb board.

4. Communication between DMX512 led digital strips are synchronized perfectly under support of Artnet / DMX512 led controllers.

5. DMX512 RGBW led pixel tape strips DMX address need to be set via DMX address coder / controller.

6. Vivid lighting performance operated by Madrix software, Artnet / DMX512 led controllers.

7. 24 pixels 72 leds DMX512 RGBW led strip is flexible , bright, durable and easy for installation.

For bare board strip, you can use the 3M adhensive tape on back; For waterproof silicone tube strip, there shipped with flexible silicon brackets and screws, the brackets fit over the waterproof sheath, it would be used to mount the led strips very well.

8. Widely used in entertainment, stage, live performance, Disco Club and TV Show, etc

Read More
24V DMX512 RGBW RGBWW LED Pixel 3D digital tape

24V 60 Leds DMX512 RGBW Pixel LED Digital Tape

Leave review
Color
RGBW
Pixel
6 led/pixel
Protocol
DMX512
Voltage
24V

1. DMX512 RGBW RGBWW Pixel LED Digital Strip

2. DC24V, 19W/M

3. 12mm width White / Black FPCB

4. Warm white 3000K, neutral white 4500K, Cool white 6500K to choose

5. 3M adhensive tape on backside of non-waterproof strip

6. Support K-1000C/ K-8000C/ YM-501 /DMX512,Artnet to control

7.Standard DMX512 Signal wire digital control interface A,B

8. Widely used in entertainment, stage, live performance, Disco Club and TV Show, etc

1. This strip is DMX 512 RGBW led digital strips that different with normal SPI led pixel strips.

DMX512 led strips protocl is DMX512 that signal is parallel not series.

2. Its advantage is parallel DMX512 signal could avoid RGBW LEDs color influenced by the failure of one light in serial connection.

3. Entire strip has 10 pixels ( 40 channels), 60 pcs RGBW leds in a meter with 12mm width pcb board.

4. Communication between DMX512 led digital strips are synchronized perfectly under support of Artnet / DMX512 led controllers.

5. DMX512 RGBW led pixel tape strips DMX address need to be set via DMX address coder / controller.

6. Vivid lighting performance operated by Madrix software, Artnet / DMX512 led controllers.

7. 10 pixels 60 leds DMX512 RGBW led strip is flexible , bright, durable and easy for installation.

For bare board strip, you can use the 3M adhensive tape on back; For waterproof silicone tube strip, there shipped with flexible silicon brackets and screws, the brackets fit over the waterproof sheath, it would be used to mount the led strips very well.

8. Widely used in entertainment, stage, live performance, Disco Club and TV Show, etc.

Read More
